ETON HEX 80 HIGH-END MELLEMTONER 80MM

High-end 80 mm (3") midrange driver with newly developed HEX cone technology and special, additional hand-applied coating with ribbed aluminum phase plug – a true milestone in development. The new, extremely lightweight honeycomb-reinforced glass fiber sandwich membrane impresses with its acoustic properties and, with the additional hand-applied coating, becomes the absolute high-end cone in this class! Voices are reproduced with extreme detail and precision for maximum stage depth, transparency, and dynamics! Powered by an extremely strong neodymium magnet with additional voice coil ventilation. Polished pole and base plates and fabulous details such as the symmetrical stranded wire guide and the extremely torsion-resistant die-cast aluminum basket make this midrange system an absolute sound quality champion! Made in Germany.
midrange80 mm (3")
Impedance4 Ω
Nominal power (RMS25 W
Music power40 W
Sound pressure level86 dB
Outer diameter94 mm
Installation depth40 mm
Nominal impedance
Zn
4
Ω
Total moving mass (incl. air mass)
MMD
4.5
g
DC resistance
Re
3.4
Ω
Effective piston area
SD
34
cm2
Voice coil inductance
Le
0.14
mH
Resonance frequency TSP
fr
91
Hz
Force factor
BLxl
4.8
Tm
Suspension compliance
CMS
0.68
mm/N
Mechanical Q
QMS
6.86
Xmax mechanical
+/-
5.4
mm
Electrical Q
QES
0.38
Equivalent air vol. of suspension
VAS
1.1
dm3
Total Q
QTS
0.36
Characteristic SPL 1W / 1 m
86
dB
Mechanical resistance
RMS
0.37
kg/s
Rated power
25/40
W
magnet material
-
Neodymium
-
voice coil diameter
25
mm
