Varenr.: 347317-1-50-p
På lager hos vores leverandør
cable diameter: 0,5 mm² - 1,5 mm²
cable diameter: 22 - 16 AWG
Technical data:
length: 35,0 mm
diameter cable entry: 4,8 mm² max.
drop length: 7,5 mm to centre stop
material: copper tin plated
insulation: Nylon (PA 66) heat shrinking with internal adhesive
shrink ratio: 3 : 1
shrink temperature: 180° min.
operating temperature: -55°C - 125°C max.
electrical current: 600V max.
REACH and RoHS compliant
UL listed
Content:
50 pieces
